Fast delivery, real price concessions
The use of sealed wiper blades greatly reduces the entry of dust and foreign objects
Equipped with wire retainer to prevent the steel ball from falling
Introduction about the miniature construction
Miniature Guide Way is designed with two rows of Gothic rails, and the balls are connected at 45° to make a circular design to achieve four-point contact and have the effect of equal load. The return channel is made of plastic injection molding, which greatly reduces the noise caused by the collision between the balls and the metal. The sealed wiper blade and the dust-proof design at the bottom of the sliding seat greatly reduce the entry of dust and foreign matter and extend the service life.
Product characteristics of miniature
【Standard Type】． Suitable for use in small-sized equipment. Stainless steel material． Strong rigidity and high precision. With retainer
Introduction about the miniature construction
Miniature Guide Way is designed with two rows of Gothic rails, and the balls are connected at 45° to make a circular design to achieve four-point contact and have the effect of equal load. The return channel is made of plastic injection molding, which greatly reduces the noise caused by the collision between the balls and the metal. The sealed wiper blade and the dust-proof design at the bottom of the sliding seat greatly reduce the entry of dust and foreign matter and extend the service life.
The model and specifications of this product are special,
If you have any needs, please refer to the electronic catalog, or join the inquiry cart, and someone will contact you!
Product introduction
. The miniature slide rail is designed with two rows of Gothic rails, and the balls are connected at 45° to make a circular design to achieve four-point contact and have the effect of equal load.
. The return channel is made of plastic injection molding, which greatly reduces the noise caused by the collision of the ball and the metal.
. The sealed wiper blade and the sliding bottom are designed to be dust-proof, which greatly reduces the entry of dust and foreign objects and prolongs the service life.
. There is a wire retainer on the side of the steel ball to prevent the steel ball from falling.
. Stable precision control, interchangeable rails of the same type, and maintain the same smoothness, precision and preload, and also convenient for assembly and maintenance
Model description
